Set up TekLan VPN for Xbox

For Xbox One and Xbox Series. The VPN profile runs on a compatible router.

Setup steps

Xbox router setup

Route the Xbox through a compatible VPN router

Xbox One and Xbox Series X|S cannot install VPN apps, so the VPN runs on your router and the console uses it. To protect only the console, the router needs its name or MAC address.

Before you begin

  • Confirm the router has a supported WireGuard or OpenVPN client and that you can sign in to its administration page.
  • Connect the Xbox to that router and identify it in the router device list.
  • Back up the router settings before changing VPN or policy-routing options.

Choose the router protocol and delivery method

Create a separate profile for the router. Use WireGuard when the selected router guide supports it, or OpenVPN when it does not.

  • WireGuard download: download the .conf file directly.
  • WireGuard email: select Send profile, then Send email to receive the .conf file.
  • WireGuard device code: select Send profile, then Get code. On the device being used to configure the router, open dash.teklanvpn.com/get, enter the code and download the file. The code expires after 15 minutes and works once.
  • OpenVPN download or email: download the .ovpn file, or send it by email from Send profile. Select Show OpenVPN credentials and keep the displayed private-key password available. Device access codes are not offered for OpenVPN.
Selecting WireGuard while creating a profile
Choose WireGuard when the router supports it.

Steps

  1. For WireGuard: create a WireGuard profile, download its .conf file and follow the router guide for a compatible WireGuard client.
  2. For OpenVPN: create an OpenVPN profile, select Set up this device, choose Router, then select the exact router or firmware.
    Selecting OpenVPN while creating a Dashboard profile
    Choose OpenVPN when that is the router's supported protocol.
    Router selected in Set up this device
    Choose Router and select its exact firmware.
  3. Follow the instructions for that router or firmware. Do not use directions written for a different router interface.
  4. Import the .conf or .ovpn file, connect the router VPN client and confirm that it stays connected.
  5. Find the console on the router. On the Xbox, open Settings › General › Network settings › Advanced settings to see its wired and wireless MAC addresses, then look for the one in use in the router’s list of connected devices.
  6. In the router policy-routing settings, assign the Xbox to the VPN profile.
  7. Restart the Xbox fully (hold the Xbox button on the console for 10 seconds, then switch it back on), then run Settings › General › Network settings › Test network connection.
  8. Test the router policy before using the Xbox.

Check the connection

  1. Confirm the VPN client reports Connected in the router administration page.
  2. Confirm the Xbox is assigned to the VPN policy rather than the normal internet route.
  3. Restart the Xbox network connection after changing the policy.
  4. If the device cannot open an IP-checking site, temporarily assign a phone to the same policy and confirm its public IP address changes.

If it does not connect

  • Generate a fresh profile and confirm that the correct router firmware was selected.
  • If the router connects but Xbox does not use the VPN, recheck its policy-routing assignment.
  • Remove any older VPN policy that also targets Xbox.
  • Check the router clock and DNS settings if the tunnel repeatedly drops.

Still stuck? See the help articles, or open a support ticket with the exact error you see.
